Full Range Speaker with High-Quality Material

Appearance

Front viewing angle: Square black plastic housing with standard mounting holes at four corners. The center is a round sound unit with dark gray rubber suspension edge and smooth diaphragm surface. "HD" (High Definition) and "16:9" logos are clearly printed on the front of the case. Side close-up: showing the sectional structure of the unit, with black rubber overhang, dark gray diaphragm, and white lead connecting the diaphragm. The side view clearly shows the thickness of the unit and the metal texture of the internal voice coil skeleton.

Features

High-resolution audio: The "HD" designation indicates that it is optimized for high-fidelity audio with a wider frequency response range Widescreen Soundstage Optimization: The "16:9" logo suggests that its acoustics are optimized for video content Durable structural design: rubber overhang provides good compliance and long-stroke potential Compact square design: saves installation space and facilitates integration of modern equipment

Advantages

Convenient installation: standard hole position is suitable for quick fixing Sound optimized: tuned for modern multimedia content Space efficiency: Square design maximizes the use of space inside the equipment Durability: excellent aging resistance of rubber overhang

Instructions

Secures to equipment panel through four corner mounting holes Make sure there is no obstruction in front of the diaphragm (leave enough acoustic space) Pay attention to the polarity of the lead when connecting (usually red is positive) Drive circuit matched to appropriate power (4-8 Ω impedance recommended)

Application Scenarios

Built-in speakers for flat panel TV/monitor In-vehicle infotainment system Multimedia audio equipment Video conference system Digital Signage Audio System Home Theater Satellite Speaker

FAQ

Q1: What is your MOQ?

A: Our standard MOQ is 100 units for regular models. We can offer a lower MOQ for pilot orders, but the unit cost will be higher.

Q2: Can we customize the color or material of the speaker?

A: Yes. Color and material customization is available for OEM/ODM orders. Please contact us with your specific requirements for a quotation.

Q3: Do you provide ODM/OEM services?

A: Yes, we specialize in ODM and OEM services. We can design and produce speakers according to your technical specifications or design drawings.

Q4: How long does it take to develop a new product?

A: The development time depends on the complexity. It typically takes 4-8 weeks for a new design, including prototyping and testing.

Q5: What are your payment terms?

A: We commonly accept T/T (Bank Transfer). For new customers, 50% deposit is required to start production, and the balance 50% before shipment.

Q6: Can I mix different products in one container?

A: Yes, mixed orders are welcome. This is a cost-effective way to import. We will provide a detailed packing list for each product.

Company Overview

Jiangxi Roxound Acoustic Company was established in 2006 and is a professional speaker manufacturer with 20 years of acoustics experience. It has established manufacturing bases in Dongguan, Jiangxi, and Vietnam. The company's products are mainly used in consumer electronics, security systems, automobiles, musical instruments, micro-sized devices, and professional applications.

We are dedicated to providing high-quality speaker units and comprehensive solutions, including free EQ and DSP tuning, passive radiator, and duct design support. Leveraging simulation software such as Finemotor, a reliability design standard library, and a pre-design database accumulated over 15 years, we ensure efficient and reliable development. We can deliver samples within 3 days, complete projects within 7 days, and have access to a professional soundproof room to guarantee the precision of acoustic testing and verification.
